Overview
1 Since the day the product leaving our factory, the Tower Crane Warranty Policy will come into force.2 The warranty period of the imported parts from manufacturer's abroad supplier should follow the warranty policy of abroad supplier.3 The warranty period of the following parts is 24 months.Steel structure4 The warranty period of the following parts is 24 months.Slewing bearing5 The warranty period of the following parts is 12 months.Hoisting Mechanism: motor, reducer and other main driving parts.Slewing Mechanism: motor, reducer and other main driving parts.Trolley Mechanism: motor, reducer and other main driving parts.Traveling Mechanism: motor, reducer, bogies and other main driving parts.Hydraulic climbing system: Pump and Cylinder.Electric control system: frequency converters, PLC (Programmable Logic Controller), AC Contactors and other main electric elements.6 The warranty period of the following parts is 3 months.Hoist limit switch, Slewing limit switch, Trolley limit switch, Traveling limit switch, Load cut out and Moment cut out.Drivers control unit, brake systems of mechanisms, cable,terminal block and wire rope.7 The warranty period for the new spare parts which replacing the faulty part will be the same as the replaced faulty part.8 The warranty period for spare parts purchased from our company is 3 months.
基本情報
モデル番号。 | QTP6015 |
インストール | ジャッキアップ |
ムービングタイプ | 修理済み |
タイプ | 上旋回クレーン |
電源 | 380V/50Hz 440V/60Hz |
必要なパワー | 55kVA/70kVA |
モデル | 40lvf20/40bpx65/Rcv95 |
輸送パッケージ | ヌード、コンテナまたはトラック |
仕様 | 1023.00cm * 235.00cm * 269.00cm |
商標 | 太陽 |
起源 | 中国 |
HSコード | 842620000 |
生産能力 | 400台/年 |
製品説明
製品説明トップレスタワークレーン
モデル | 最大荷重 | 作動範囲 | チップロード | マストセクション |
QTP8040 | 25T | 80M | 4T | 2.5*2.5*5.95メートル |
QTP8040 | 20T | 80M | 4T | 2.5*2.5*5.95メートル |
QTP7530 | 20T | 75M | 3T | 2*2*3M |
QTP7530 | 16T | 75M | 3T | 2*2*3M |
QTP7022 | 12T | 70M | 2.2T | 2*2*3M |
QTP7025 | 10T | 70M | 2.5T | 2*2*3M |
QTP7015 | 10T | 70M | 1.5T | 2*2*3M |
QTP6513 | 8T | 65M | 1.3T | 2*2*3M/1.6*1.6*3M |
QTP6015 | 8T | 60M | 1.5T | 2*2*3M/1.6*1.6*3M |
QTP6013 | 6T | 60M | 1.3T | 1.6*1.6*3 メートル |
